Allen Bradley AB Operator Interface PanelView 1000e

Allen-Bradley PanelView 1000e Operator Interface

The Allen-Bradley PanelView 1000e is a high-performance Human-Machine Interface (HMI) designed to provide operators with intuitive control and monitoring capabilities in complex industrial environments. This robust terminal is engineered to enhance operational efficiency and integrate seamlessly with various automation systems.

Key Features

• Display: 10.4-inch color TFT active-matrix screen with a resolution of 640 x 480 pixels, delivering clear and detailed visuals for precise process monitoring.
• Input Methods: Available in both touchscreen and keypad configurations to suit diverse operational preferences and requirements.
• Communication Interfaces: Equipped with Data Highway Plus (DH+) and Remote I/O (RIO) communication ports, facilitating seamless integration with Allen-Bradley PLCs and other industrial control systems.
• Memory: 2.25 MB of onboard flash memory, expandable up to 15.75 MB using a PC memory card, accommodating extensive application data and configurations.
• Power Supply: Supports a wide input voltage range of 90–132V AC and 180–264V AC, ensuring compatibility with various power systems.
• Durability: Designed with a NEMA 4X (indoor use only) rating, offering protection against dust and water ingress, making it suitable for demanding industrial environments.

Applications

The PanelView 1000e is ideal for a range of industrial applications, including:

• Manufacturing process automation
• Material handling and conveyor systems
• Oil and gas monitoring and control
• Water treatment and utilities
• Food and beverage production lines

Installation and Compatibility

Featuring a clip mount design, the PanelView 1000e allows for straightforward installation into control panels. It is compatible with Allen-Bradley PLC-5 and SLC 500 controllers that support DH+ or RIO communication protocols. Programming and configuration are facilitated through the PanelBuilder 1400e software, providing a user-friendly interface for application development.

By integrating the Allen-Bradley PanelView 1000e into your automation system, you can achieve enhanced control, monitoring, and operational efficiency, ensuring reliable performance in complex industrial processes.
