Allen Bradley AB MicroLogix 1500 Base Unit 1764-28BXB /B Rev A Missing Cover
PLC Processors
Allen Bradley AB MicroLogix 1500 Base Unit 1764-28BXB /B Rev A Missing Cover
Price
$239.99
SKU
Condition
Availability
C-2-4-574
Used
1 in stock
Free Shipping
On orders over $50
Easy Returns
30-day return policy
Secure Payment
100% secure
| Condition | Used |
|---|---|
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Model / Part Number | 1764-28BXB |
| Series | MicroLogix 1500 |
| Unit Type | Base Unit |
| Input Voltage | 24V DC (20.4–30V DC) |
| Inputs | 16 points (8 standard 24V DC, 8 fast 24V DC) |
| Outputs | 12 points (6 relay, 4 standard FET, 2 fast FET, all 24V DC) |
| High-Speed I/O | 8 inputs, 2 outputs at 20 kHz |
| Power Supply Rating | 30 watts |
| User Power Output | 24V DC at 400 mA (max) |
| Communication Port | RS-232 (1 port) |
| Operating Temperature | 0°C to +55°C (+32°F to +131°F) |
| Operating Humidity | 5–95% relative humidity (non-condensing) |
| Mounting | DIN Rail |
| Dimensions | 168 mm W × 87 mm D × 138 mm H (open) / 118 mm H (closed) |
| Enclosure Rating | IP20 |
| Compatible Processors | 1764-LRP, 1764-LSP |
