Allen Bradley AB Booted HD Green Cap Push Button Unit 800H-R1A /F

Allen-Bradley 800H-R1A /F Booted Head Green Cap Push Button Unit

The Allen-Bradley 800H-R1A /F is a 30mm momentary push button designed for industrial applications requiring reliable and durable control solutions. Featuring a booted head with a green cap, this unit ensures enhanced protection and visibility in various operating environments.

Key Features

• Operator Cap Type: Booted head with a round, green synthetic rubber cap.
• Contact Configuration: Equipped with 1 Normally Open (NO) and 1 Normally Closed (NC) standard contact block (800T-XA).
• Electrical Ratings: Supports a thermal current rating of 10 A, with operational voltage up to 600V AC/DC. Utilization categories include A600 (AC-15) and Q600 (DC-13).
• Mechanical Durability: Designed for a minimum mechanical lifespan of 10 million cycles, ensuring long-term reliability.
• Environmental Compatibility: Suitable for NEMA Type 1, 4, 4X, 12, and 13 enclosures, offering versatility across different industrial settings.
• Operating Conditions: Functions effectively within a temperature range of -25°C to 50% humidity.
• Certifications: Complies with ABS, CCC, CE, CSA, EAC, GOST, and UL standards, affirming its adherence to international safety and performance requirements.

Applications

The 800H-R1A /F push button unit is ideal for use in control panels, machinery interfaces, and other industrial equipment where a momentary push button is required. Its robust construction and protective booted head make it suitable for environments where durability and reliability are paramount.

Installation and Maintenance

Designed for easy installation, the unit fits standard 30.5 mm mounting holes and utilizes screw connections for secure wiring. The contact blocks are rated for a tightening torque of 6 – 8 in-lb (0.7 – 0.9 N-m) and accommodate wire ranges from 14 to 18 AWG. Regular inspection and maintenance are recommended to ensure optimal performance over its extensive operational lifespan.

For detailed technical specifications and installation guidelines, please refer to the manufacturer’s documentation.
