Overview
The Allen-Bradley 800T-XA is a shallow contact block for the 800T series of 30mm push buttons. It is used for 800T and 800H series 30mm push buttons and provides 1 NO (normally open) and 1 NC (normally closed) contact configuration. This non-metallic contact block delivers robust electrical switching in demanding industrial environments with a voltage rating of 600VAC.
Key Features
- Base mounted with screw attachment
- Contact rating of 10 A at 230 VAC
- Single pole, shallow design for compact panel integration
- CCC certified, CE-LVD certified, CSA certified, MARINE-ABS, and C/US UL listed
- Non-metallic construction for reliable long-term operation
Technical Specifications
- Contact Configuration: 1 NO / 1 NC
- Voltage Rating: 600VAC
- Contact Current: 10A @ 230VAC
- Mounting Type: Base
- Number of Poles: 1
- Push Button Size: 30mm
- Terminal Type: Screw
- Length: 1-27/64 inches (1.42 inches)
- Height: 1-25/32 inches (1.78 inches)
- Certifications: CCC, CE-LVD, CSA, MARINE-ABS, UL
- Material: Non-Metallic
Typical Applications
The 800T-XA contact block serves as a drop-in accessory for pushbutton stations, selector switches, and control panels requiring dual-contact switching logic. Common uses include:
- Industrial machinery start/stop control
- Safety interlocks and emergency stop circuits
- Process automation and pump/motor control
- Operator interface panels in manufacturing facilities
- HVAC and building automation systems
Compatibility & Replacements
Compatible With
- Allen-Bradley 800T series 30mm push buttons
- Allen-Bradley 800H series 30mm push buttons
- Standard industrial control panel wiring (600VAC circuits)
- NEMA 4 and NEMA 13 rated enclosures
Replaces / Drop-In Replacement For
- 800T-XA (original part number)
- Contact block assemblies for older 800T pushbutton installations
Works With
- Allen-Bradley control systems and PLCs
- Standard 24VDC and 120VAC control circuits
- Programmable logic controllers with discrete input/output modules
- Industrial automation platforms utilizing pushbutton operator stations
