Overview
The Allen-Bradley 700-HN100 is an 8-pin tube-base relay socket designed for use with DPDT Bulletin 700-HA relays and timing relay variants. This guarded socket provides a secure, touch-safe connection point for industrial automation, control systems, and machine logic applications. Available in boxes of 6, it is a proven drop-in replacement for existing installations.
Key Features
- 8-pin tube base socket with screw terminal connections
- Guarded terminal construction for operator safety and arc protection
- Dual-mount capability: panel or DIN rail mounting
- Compatible with 700-HA32, 700-HR, 700-HX, 700-HT, 700-HRM, 700-HRC, and 700-HV relays
- International certifications: UL, CSA, CUL, CE, CCC, KC
- Supplied in box of 10 per package (standard production packaging)
Technical Specifications
- Part Number: 700-HN100
- Manufacturer: Rockwell Automation / Allen-Bradley
- Number of Pins: 8
- Socket Type: Tube Base
- Terminal Type: Guarded Touch Safe Screw
- Voltage Rating: 300–400 VAC
- Amperage: 10 A
- Mounting: DIN Rail / Panel Mount
- Dimensions: 38 mm W × 26 mm D × 65 mm H
- Weight: 0.11 lbs (per unit)
- Certifications: UL, CSA, CUL, CE, CCC, KC
- Material: Phenolic / Plastic with metal contacts
Typical Applications
- Industrial relay control panels and switchgear
- PLC I/O module interface bases
- Automation cabinet wiring termination
- Motor starter logic circuits
- Process control and sequence timing circuits
- Machine safety and interlocking systems
Compatibility & Replacements
The 700-HN100 is the base socket for all 700-series relay types: 700-HA (DPDT relays), 700-HX (timing relays), 700-HT (on-delay timers), 700-HRM, 700-HRC, and 700-HV (repeat cycle timers). It is a direct, catalog-standard replacement across all Rockwell and legacy Allen-Bradley control systems. No firmware or configuration required—simple mechanical swap. Verify relay type before ordering to ensure coil voltage compatibility.
