The Allen-Bradley 855T-B24TL5 is a 70 mm amber steady LED stack light module designed for industrial signaling applications.
Key Features
- Voltage Compatibility: Operates efficiently at 24V AC/DC, accommodating various industrial power systems.
- Energy Efficiency: Consumes only 29 mA, ensuring minimal energy usage.
- High Visibility: Delivers a light output ranging from 1,400 to 3,550 millicandela, providing clear status indication.
- Durability: Features a robust black housing with an amber lens, offering a lamp lifespan of 100,000 hours.
- Environmental Protection: Boasts NEMA 4X and IP65 ratings, ensuring resistance to dust and moisture.
- Temperature Resilience: Operates reliably within a temperature range of -25°C to 70°C.
Applications
Ideal for machine status indication, process monitoring, and visual alarms in manufacturing and assembly lines.
Specifications
- Outer Diameter: 70 mm
- Housing Color: Black
- Lens Color: Amber
- Operating Voltage: 24V AC/DC
- Current Consumption: 29 mA
- Light Output: 1,400 to 3,550 millicandela
- Protection Ratings: NEMA 4X, IP65
- Operating Temperature: -25°C to 70°C
- Storage Temperature: -40°C to 85°C
- Humidity Range: 5% to 95% without condensation
- Recommended Wire Size: 0.5 mm²
- Terminal Torque: 0.8 Nm
- Lamp Lifespan: 100,000 hours
The 855T-B24TL5 stack light module is a reliable and efficient solution for industrial signaling needs, offering high visibility and durability in demanding environments.
