Overview
The Allen-Bradley 60-2649 is a swivel/tilt photoelectric mounting bracket engineered for RightSight 42EF photoelectric sensors. Constructed from durable Valox plastic, this bracket delivers precise positioning and stability in demanding industrial automation environments. The compact design supports 360-degree rotation and ±10-degree vertical tilt adjustment, making it ideal for applications requiring flexible sensor alignment without mechanical rework.
Key Features
- Swivel/Tilt Design: ±10 degrees from vertical with full 360-degree rotation capability
- 18mm Thread Compatibility: Direct mount for RightSight 42EF series sensors
- Valox Construction: Durable plastic housing for industrial environments
- Compact Profile: Minimal footprint suitable for confined installation spaces
- Standard Compliance: Meets CCC and KC certifications
Technical Specifications
- Part Number: 60-2649
- Manufacturer: Allen-Bradley / Rockwell Automation
- Product Type: Photoelectric Mounting Bracket
- Material: Valox (engineered plastic)
- Thread Size: 18mm
- Adjustment Range: ±10 degrees tilt, 360 degrees rotation
- Weight: 0.16 lbs (0.07 kg)
- Certifications: CCC, KC
- UPC: 662072038604
Typical Applications
The Allen-Bradley 60-2649 mounting bracket is widely used in:
- Material handling and conveyor systems requiring precise object detection
- Packaging equipment where sensor alignment flexibility is critical
- Assembly lines requiring stable, repositionable sensor mounting
- Industrial automation systems with space constraints
- General-purpose photoelectric sensing installations
Compatibility & Replacements
Compatible With
- Allen-Bradley RightSight 42EF photoelectric sensors (M18 variant)
- Industrial automation sensor mounting applications
- Standard 18mm threaded sensor housings
- Rockwell Automation photoelectric sensor systems
Replaces / Drop-In Replacement For
- Previous-generation Allen-Bradley photoelectric mounting brackets requiring similar thread and rotation specifications
- Generic 18mm swivel/tilt sensor mounts in RightSight installations
Works With
- Allen-Bradley 42EF RightSight photoelectric sensors
- Material handling and packaging machinery control systems
- Rockwell Automation industrial sensor ecosystems
- Standard industrial photoelectric sensing platforms
