Overview
The Allen-Bradley 194R-N60-1753 is a non-fused rotary disconnect switch manufactured by Rockwell Automation. This 60 amp non-fused disconnect switch provides robust electrical isolation for three-phase 60A circuits in industrial control cabinets and panel installations. Rugged and durable, 194R non-fused disconnect switches are approved for demanding applications and environments, with touch-safe design, OSHA padlocking, and front or side operation.
Key Features
- Non-fused type with 60 amp rating at 600 volts, 3-pole configuration
- Includes OSHA padlocking provisions for safety lockout compliance
- Touch-safe design with front or side operation options
- Screw terminal connections for reliable conductor interface
- Supports conductor sizes 14–4 AWG with 10,000 operating cycles rated
- Kitted design allows integration with optional handle and shaft configurations
Technical Specifications
The following specifications are verified from multiple distributor technical sheets:
Typical Applications
Suitable for food processing, electrical machinery, and material handling operations. The 194R-N60-1753 is commonly deployed in industrial motor control centers, electrical distribution panels, and process automation systems requiring reliable circuit isolation and safety-rated padlocking.
Compatibility & Replacements
The base 194R-N60-1753 unit is supplied without a handle or shaft. Related variants include the 194R-N60-1753-PBS1 (with black pistol handle and 12-inch S1 shaft), 194R-N60-1753-PYS1 (with red/yellow handle), and 194R-N60-1753-PYN2 (complete NEMA 4/4X assembly with 21-inch shaft and guard tube). All 194R series disconnect switches share the same electrical ratings and mounting envelope, making them drop-in substitutes where handle and enclosure configurations differ. Verify specific handle orientation and shaft length requirements before ordering.
