Overview
The Allen-Bradley 194E-E100-NP is an additional pole module rated for 100 amperes, engineered for seamless integration with 194E series load switches in industrial automation and motor control systems. This Series B 4th pole unit expands switching configurations without requiring system redesign, making it ideal for retrofits and multi-pole isolation applications requiring field upgrades.
Key Features
- 100-ampere current rating for reliable three-phase and multi-circuit distribution
- High-quality copper construction ensuring superior electrical conductivity and stable contact resistance
- CE, UL, and CSA certified for global safety and compliance standards
- Engineered for harsh industrial environments with tolerance to temperature extremes and vibration
- Drop-in compatibility with 194E-series load switch bodies—no modifications required
- Straightforward installation minimizing system downtime and labor costs
Technical Specifications
The 194E-E100-NP is designed as an auxiliary circuit element for multi-pole applications. It meets industrial-grade performance standards and integrates with existing 194E installations to support expanded load switching capabilities. The module’s copper core and robust mechanical design provide long-term reliability in demanding environments.
Typical Applications
- Expanding three-pole switches to four-pole or greater configurations
- Motor starter and soft-starter disconnect installations
- Industrial automation control panels requiring multi-pole isolation
- Equipment retrofits where additional switching circuits are required
- Ground, neutral, and auxiliary terminal additions to existing switchgear
- IEC and NEMA-rated disconnect switching systems
Compatibility & Replacements
Compatible With
- Allen-Bradley 194E-series load switch bodies (all frame sizes)
- 100-ampere rated disconnect switch installations
- Three-phase and multi-circuit industrial control systems
- Standard DIN rail and panel-mount enclosure configurations
- IEC 947-3 and NEMA-compliant switchgear designs
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or automation technician before ordering to confirm pole configuration requirements.
Works With
- All Allen-Bradley 194E load switch bodies and frame styles
- Rockwell Automation industrial control and motor control platforms
- IEC 947-3 and NEMA-rated disconnect switching architectures
- Auxiliary contact blocks and extension modules for 194E series installations
- Standard three-phase and multi-circuit control panel designs
