Overview
The Allen-Bradley 1485P-P1E4-R5 is a sealed DeviceNet connection device with KwikLink heavy-duty connector technology. This micro female connector features insulation-displacement design for secure, field-terminable connections on DeviceNet flat media systems. Engineered for industrial automation environments requiring robust, sealed connectivity without external tools.
Key Features
- KwikLink heavy-duty connector with sealed design for environmental protection
- Insulation-displacement connector (IDC) technology for fast field termination
- Micro female form factor—compact design for space-constrained installations
- Standard version compatible with DeviceNet flat media (KwikLink system)
- Single port, pre-configured with base mount
- Manufactured to Allen-Bradley reliability standards
Technical Specifications
- Part Number: 1485P-P1E4-R5
- Product Type: DeviceNet Connection Device
- Connector Type: KwikLink Heavy-Duty Micro Female, Sealed
- Connection Method: Insulation-Displacement Connector (IDC)
- Rated Voltage: 24 Volt DC
- Rated Current: 3 Ampere
- Ports: 1 Port, Standard
- Material: Valox (polyester-imide resin)
- Media System: DeviceNet Flat Media System—KwikLink
- Connector Version: Standard
- UPC: 662072775646
Typical Applications
- DeviceNet node termination and branching
- Industrial control and automation systems
- Manufacturing equipment networking
- Motor and drive control interconnection
- Sealed connector environments requiring field-installed terminations
- System integrations requiring hot-swappable DeviceNet devices
Compatibility & Replacements
Compatible With
- Allen-Bradley DeviceNet communication systems
- CompactLogix and ControlLogix controllers with DeviceNet adapters
- Devices using DeviceNet flat-media KwikLink connections
- Industrial I/O modules, drives, and sensors with DeviceNet capability
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The 1485P-P1E4-R5 is a sealed micro female variant. Similar models in the 1485P series include the 1485P-K1E4-R5 (micro female, general purpose), but specification differences require verification before substitution.
Works With
- DeviceNet flat media (KwikLink heavy-duty system)
- Studio 5000 software (device configuration and diagnostics)
- RSNetWorx for DeviceNet (network configuration tool)
- Allen-Bradley DeviceNet scanner modules
- EtherNet/IP gateways with DeviceNet bridges
