Overview
The ABB T1N060TLA is a molded-case circuit breaker from the Tmax T1 family designed for industrial and commercial electrical distribution systems. This 60-ampere, 3-pole thermal-magnetic breaker offers reliable overcurrent protection with fixed mounting configuration. It combines electromagnetic relay technology for short-circuit detection with heat-sensitive bimetal elements for overload protection, meeting UL489 and CSA C22.2 No. 5 standards.
Key Features
- 60A rated thermal-magnetic trip unit with non-interchangeable, precise electromagnetic relays
- 3-pole configuration for three-phase circuit protection in industrial applications
- Fixed mounting design with clamp-type terminals for secure electrical connections
- Rated for 240V–600V AC operation, compatible with typical industrial distribution voltages
- UL489 and CSA C22.2 No. 5 certification; IEC 60947-2 rated for global acceptance
- Compact profile with state-of-the-art contact and arcing chamber construction to limit fault currents
Technical Specifications
- Part Number: T1N060TLA / E93565
- Ampere Rating: 60A
- Poles: 3 (three-pole fixed)
- Voltage Rating: 240–600V AC
- Trip Type: Thermal-Magnetic
- Mounting: Fixed (plug-in not available for T1 series)
- Terminal Type: Clamp terminals
- Certifications: UL489, CSA C22.2 No. 5, IEC 60947-2
- Condition: New, no original packaging
Typical Applications
The ABB T1N060TLA is ideal for:
- 3-phase industrial feeder and branch circuit protection
- Manufacturing equipment and motor control circuits
- Commercial building distribution panels (480V/600V)
- Reverse-feed applications and load-side protection
- Systems requiring reliable thermal and magnetic overcurrent detection without electronic trip units
Compatibility & Replacements
The ABB T1N060TLA is a fixed-frame T1 breaker; trip units are non-interchangeable across the T1 family. This part is suitable for use in industrial distribution systems rated 240–600V AC. Upgrading or replacing this breaker with later-generation Tmax series (T2, T3, T4, T5) requires frame compatibility assessment. For reversals or replacement recommendations within the T1 family, consult ABB technical documentation or contact your distributor. New condition stock ensures compatibility with existing panel layouts and terminal arrangements.
