Overview
The Dongan A06-SA6 is a proven interchangeable ignition transformer designed for industrial and commercial heating applications. With a 120 VAC primary input and 6000 VAC secondary output, this transformer delivers the high voltage needed for oil and gas furnace ignition, igniter control, and electrode systems. The base-mounted design and end-grounded secondary winding ensure safe, reliable operation in demanding environments.
Key Features
- 120 VAC primary to 6000 VAC secondary voltage rating
- 175 VA power rating; 20 mA secondary current capacity
- 60 Hz; UL approved for industrial use
- Base-mounted with single screw terminal for secure installation
- End-grounded secondary winding for safety and arc suppression
- Compact enclosed NEMA 1 steel enclosure
Technical Specifications
- Primary Voltage: 120 VAC
- Secondary Voltage: 6000 VAC
- Frequency: 60 Hz
- Power Rating: 175 VA
- Secondary Current: 20 mA
- Mounting: Base plate mounted
- Terminals: Single screw terminal (primary), grounded secondary
- Enclosure: NEMA 1 (steel, industrial-duty)
- Weight: 4 kg (approximately 8.8 lbs)
- Certifications: UL approved
- Winding Configuration: End-grounded
Typical Applications
The Dongan A06-SA6 is widely used in:
- Oil and gas furnace ignition systems
- Bakery and food processing ovens
- Grain dryers and agricultural heating
- Heat-treating and industrial ovens
- Burner ignition and electrode control circuits
- Commercial and industrial heating installations
Compatibility & Replacements
Compatible With
- 120 VAC single-phase control circuits
- Oil and gas burner control systems
- Furnace ignition modules and electrode systems
- Industrial heating and combustion control panels
- Standard industrial control cabinet wiring (120V nominal)
Replaces / Drop-In Replacement For
- Pioneer Transformer equivalents (Dongan subsidiary)
- Generic ignition transformers rated 120V–6000V, 175 VA
- Legacy part numbers: 1092-F, 12178, 22042, 39887
- Cross-references: 511-802-625, 612-6A020, 612-6A020E, 612-6A7, 612-6A7V
Works With
- NEMA-standard control enclosures and panel boards
- Industrial furnace and boiler control systems
- 120V nominal supply line conditioning and protection circuits
- All standard high-voltage electrode and igniter wiring harnesses
- Honeywell, Johnson Controls, and other furnace control modules
