Overview
The Eclipse 5600-90A is a high-sensitivity ultraviolet (UV) flame scanner designed for reliable flame detection in industrial combustion applications. This 90-degree right angle mounted scanner detects both gas and oil flames that cycle on and off frequently. The Eclipse flame safeguard checks for a short-circuited, or “run-away” scanner at the beginning and end of each flame cycle, providing critical protection against control system failures.
Key Features
- High-sensitivity UV detection: High sensitivity ultraviolet (U.V.) for monitoring gas or oil flames which cycle on and off frequently
- 90-degree right angle mount: Optimized sighting angle for burner flame detection with aluminum housing
- Run-away scanner protection: Built-in safeguard against short-circuited scanners
- Industry certifications: The scanner is UL listed, CSA certified and FM approved
- Extended cable lead: It comes with a 10 ft (305 cm) lead
Technical Specifications
- Model: 5600-90A
- Part Number: 49600-90
- Mount Type: 90° right angle (1/2″ NPT pipe nipple)
- Supply Voltage: 325 V DC
- UV Sensitivity Range: 185–260 nm (ultraviolet spectrum)
- Operating Temperature Range: -20° to 125°C (0° to 257°F)
- Housing Material: Aluminum with plated steel components
- UV Tube: Quartz construction filled with high-temperature sensitivity gas
- Cable: 10-foot lead (305 cm)
- Weight: 0.60 lbs
- Origin: USA manufactured
Typical Applications
- Industrial furnace and boiler flame detection
- Gas and oil burner combustion control systems
- Pilot flame and main flame monitoring in heating equipment
- Process heating and thermal processing applications
- Equipment requiring frequent on/off flame cycling detection
Compatibility & Replacements
Compatible With
- 5600 and VF56 series Veri-Flames, the 6000 Series Multi-Flame and 6500 Series Bi-Flame controllers, or series 7000 Peek-A-Flame
- Honeywell Eclipse combustion control systems
- Industrial burner management systems requiring 325 V DC supply
Replaces / Drop-In Replacement For
- Eclipse 49600-90 (original part number)
- Alternative designation: 560090A, EC560090A
- Earlier or equivalent 90-degree UV scanner modules in Eclipse product lines
Works With
- Fireye SB49600-90 (functional replacement scanner)
- Magnifying lens assembly (Part #49600-98) for enhanced sighting
- 1/2″ insulated coupling (Part #49099) for thermal protection
- Scanner support and lens replacement components (Part #20722)
- Honeywell/Eclipse flame safeguard controllers and logic modules
