Overview
The Allen-Bradley 2090-CHB1FS8-12AA12 is a premium Kinetix 6000M IPIM hybrid motor cable designed by Rockwell Automation for high-performance servo and motion control applications. This 12-meter cable integrates power, feedback, and brake conductors into a single shielded cable assembly, reducing installation complexity and improving system reliability in demanding manufacturing environments.
Key Features
- Hybrid cable design combining motor power, feedback, and brake conductors in one shielded cable
- Optimized for Kinetix 6000M servo drive systems and IPIM applications
- 12-meter length suitable for extended motor-to-drive distances
- SpeedTec connector compatibility for standard connection protocols
- Series A construction with robust material selection for industrial environments
- Pre-engineered for Rockwell Kinetix servo motion platforms
Technical Specifications
- Part Number: 2090-CHB1FS8-12AA12
- Series: A
- Cable Length: 12 meters
- Cable Type: Hybrid (Power, Feedback, Brake)
- Application: Kinetix 6000M IPIM servo drives
- Conductor Configuration: Integrated shielded design
- Connector Type: SpeedTec compatible
- Manufacturer: Allen-Bradley (Rockwell Automation)
Typical Applications
This hybrid cable is commonly deployed in:
- Kinetix 6000M servo drive installations requiring integrated power and feedback transmission
- Multi-axis motion control systems with extended motor-to-controller distances
- Automated manufacturing equipment including packaging, assembly, and material handling systems
- Industrial robotic systems requiring synchronized servo motor control
- OEM integrations where cable management and signal integrity are critical
Compatibility & Replacements
The 2090-CHB1FS8-12AA12 is part of the Kinetix 2090 motor cable family and is designed specifically for Kinetix 6000M IPIM servo systems. As a hybrid cable with integrated power, feedback, and brake conductors, it is not directly interchangeable with single-function cables. Verify drive compatibility and cable length requirements before ordering. For alternative lengths in the same series, consult Rockwell Automation distributors or refer to publication KNX-TD004 for the complete Kinetix cable specifications catalog. For questions regarding product availability or compatibility, contact your authorized Allen-Bradley distributor.
