Overview
The TE Connectivity 206150-1 is a rugged 37-position circular connector plug assembly from the CPC Series 1 (Circular Plastic Connector) product line. This cable-mount plug is engineered for industrial control, signal distribution, and low-current power applications. Featuring a thermoplastic housing with a Size 23 shell, it delivers reliable signal transmission in demanding environments while maintaining cost-effectiveness compared to metal alternatives.
Key Features
- 37 Contacts – Dense contact arrangement for multiple signal paths in a compact form factor
- 600VAC/600VDC Operating Voltage – Rated for industrial power and control circuits
- Cable Mount (Free-Hanging) – Straightforward in-line installation without panel cutouts
- Thermoplastic Housing – UL 94V-0 flame-rated, self-extinguishing black nylon 6/6 GF material
- Threaded Coupling Ring – Quick-lock screw-down mating with positive lock feature prevents accidental disconnection
- Crimp Contact Socket Design – Supports field assembly and rapid repair with replaceable contacts
Technical Specifications
The 206150-1 delivers consistent electrical and mechanical performance:
- Manufacturer: TE Connectivity (AMP brand)
- Part Number: 206150-1
- Contact Count: 37 positions
- Connector Shell Size: 23
- Operating Voltage: 600VAC / 600VDC
- Operating Temperature Range: -55 to +105°C
- Contact Type: Crimp socket (contacts not included)
- Housing Material: Black thermoplastic (nylon 6/6 GF)
- Mounting Style: Cable mount, free-hanging
- Coupling Style: Threaded coupling nut (1-3/8 – 18 UNEF-2A thread)
- Body Orientation: Straight
- UL Rating: UL 94V-0 flammability
- RoHS Compliant: Yes
Typical Applications
The TE Connectivity 206150-1 is suited for:
- Industrial Machinery & Automation – Signal and control interconnects in manufacturing equipment and material handling systems
- Transportation & Rail Systems – Robust connector solution for transit vehicles and rail control applications
- HVAC & Building Systems – Commercial climate control and building automation signal transmission
- Process Control & Instrumentation – Low-current signal distribution in measurement and monitoring systems
- Lighting & Signage – Reliable multi-pin interconnection for outdoor and industrial display systems
- Agricultural & Construction Equipment – Vibration-resistant connectors rated for harsh field environments
Compatibility & Replacements
Compatible With
- TE Connectivity CPC Series 1 receptacle housings (panel mount and free-hanging)
- TE Connectivity MultiMate pin and socket contacts (Size 16 standard)
- Type III+, Type II, and subminiature coaxial contact formats
- Industrial automation control systems requiring 37-pole signal distribution
- Standard industrial wiring harnesses and cable assemblies
Replaces / Drop-In Replacement For
- Earlier AMP CPC Series 1 37-position cable mount plugs using identical shell geometry
- Verify part-number compatibility with your original equipment drawings or system documentation before substitution
Works With
- CPC Series 1 panel-mount and free-hanging receptacles
- MultiMate crimp contacts (standard size 16 format)
- Flexible conduit and industrial cable assemblies
- Wire-to-wire connection systems in process control and industrial automation
- Field-assembled crimp terminations on-site or in the field
