Overview
The Allen-Bradley 1336-M0D-L3 is a dedicated logic interface board engineered to integrate external control signals with the 1336 series adjustable frequency drive. This interface board facilitates remote logic control, allowing operators and automation systems to command motor start, stop, jog, and speed reference functions. Built to NEMA Type 4 standards, the 1336-M0D-L3 provides a self-contained, enclosed assembly that simplifies field wiring and improves reliability in demanding industrial environments.
Key Features
- NEMA Type 4 enclosure rating for protection against dirt, moisture, and corrosive environments
- 115V DC operating voltage—compatible with standard industrial control systems
- Self-contained assembly design reduces installation complexity and field wiring labor
- Integrates seamlessly with Bulletin 1336 AC drives for coordinated motor control
- Proven architecture supports start, stop, jog, and speed reference signal conditioning
Technical Specifications
- Part Number: 1336-M0D-L3 (also 1336-MOD-L3)
- Manufacturer: Allen-Bradley / Rockwell Automation
- Product Type: Logic Interface Control Board
- Operating Voltage: 115V DC
- Enclosure Rating: NEMA Type 4
- Compatibility: Bulletin 1336 Adjustable Frequency Drive
- Control Functions: Start, Stop, Jog, Speed Reference, Reverse
- Alternative Part Numbers: 120675, SP-120675, SP-120673, 148294
- Condition: New – No Box
Typical Applications
The 1336-M0D-L3 is widely used in industrial automation systems requiring discrete logic control of AC motor drives. Common applications include:
- Manufacturing line conveyor control and sequencing
- Pump and fan motor speed regulation with remote inputs
- Machine tool spindle control with operator interface panels
- HVAC and process cooling system automation
- Material handling equipment requiring coordinated motor operation
Compatibility & Replacements
The 1336-M0D-L3 is fully compatible with the Bulletin 1336 series adjustable frequency drive family. Alternative and equivalent part numbers include 120675, SP-120675, SP-120673, and 148294. When sourcing replacements, verify the target 1336 drive model and version to ensure feature compatibility. This board is commonly paired with the 1336-MOD-G2 graphics option and optional control panels (FA2, RP2, RP3) for enhanced user interface capability. For firmware version compatibility information, consult the 1336 drive’s instruction manual and contact Allen-Bradley technical support if uncertain.
