Overview
The UPA Technology 07-24882 CB-5 circuit board guide is a precision measurement accessory designed for coating and plating thickness inspection on printed circuit boards (PCBs). UPA Technology specializes in developing instruments and thickness standards for the PCB and electronics industries. The CB-5 guide facilitates accurate probe positioning to enable reliable measurements of plating thickness on circuit board surfaces, making it an essential tool for PCB manufacturers and quality control professionals.
Key Features
- Precision-engineered guide for accurate probe positioning on printed wiring boards
- Supports plating thickness measurements (gold, solder, tin, copper, rhodium, tin-nickel, photo-resist)
- Portable design allows measurements across entire board surface
- Compatible with UPA Technology measuring instruments and probes
- Industry-standard accessory for PCB quality assurance workflows
Technical Specifications
- Manufacturer: UPA Technology
- Model Number: 07-24882
- Product Type: Circuit Board Guide
- Variant: CB-5
- Application: Plating thickness measurement and inspection
- Compatible Probes: UPA Technology measurement probes
- Condition: New – Open Box
Typical Applications
- PCB manufacturing quality control and inspection
- Plating thickness verification on circuit board fingers and pads
- Electronics assembly verification for coating compliance
- In-process measurement during PCB plating operations
- Incoming goods inspection and supplier verification
Compatibility & Replacements
Compatible With
- UPA Technology plating thickness measuring instruments
- UPA Technology measurement probes (HH series and equivalents)
- Standard PCB fixtures and measurement workstations
- Industry-standard plating thickness standards and gold standards
Replaces / Drop-In Replacement For
Verify with your system integrator or UPA Technology for compatible replacement part numbers.
Works With
- UPA Technology coating measurement systems
- PCB plating inspection workflows
- Quality management and documentation systems
- Standard measurement calibration standards and reference plates
