West-Cap W30998 Capacitor

The West-Cap W30998 Capacitor is a fixed metallized paper capacitor designed for reliable performance in various electronic applications.

Key Features

• Capacitance: 1.0 microfarad (µF)
• Voltage Rating: 200 volts DC
• Capacitance Tolerance: ±5%
• Operating Temperature Range: -55°C to +85°C
• Case Material: Plastic
• Terminal Type: Two uninsulated wire leads

Physical Dimensions

• Body Length: 1.220 inches (31.0 mm) maximum
• Body Width: 0.560 inches (14.2 mm) maximum
• Body Height: 0.430 inches (10.9 mm) maximum
• Terminal Length: 1.500 inches (38.1 mm) minimum
• Terminal Diameter: 0.032 inches (0.81 mm) nominal

Performance Characteristics

• Insulation Resistance: 30,000 megohms
• Dissipation Factor: 1.0%

The W30998 Capacitor’s robust design and precise specifications make it suitable for applications requiring stable capacitance and reliable performance across a wide temperature range.
