TDS-08A 12V DC Open Frame Linear Solenoid Push-Pull Actuator
The TDS-08A is a versatile 12V DC open frame linear solenoid actuator designed for applications requiring precise push-pull operations. Its compact and efficient design makes it suitable for various industrial and commercial uses.
Key Features
- Voltage Options: Operates efficiently at 12V DC, with additional configurations available for 6V and 24V DC to accommodate diverse application needs.
- Compact Dimensions: Measures approximately 20mm x 26mm x 36.8mm, facilitating integration into space-constrained environments.
- Continuous Duty Cycle: Engineered for continuous operation with a power rating of 3.4W, ensuring reliable performance over extended periods.
- Electrical Specifications: At 12V DC, it has a coil resistance of 42 ohms and draws a current of 286mA, balancing energy efficiency with effective force output.
- Push-Pull Functionality: Designed to perform both pushing and pulling actions, enhancing its adaptability across various mechanical systems.
Applications
The TDS-08A solenoid actuator is ideal for:
- Automated machinery requiring precise linear motion control.
- Locking mechanisms in security systems.
- Vending machines and dispensing equipment.
- Medical devices necessitating accurate actuation.
- Other industrial applications where reliable push-pull actuation is essential.
Design and Construction
Featuring an open frame design, the TDS-08A ensures efficient heat dissipation and ease of maintenance. The solenoid’s plunger is crafted for smooth linear movement, and the coil is wound to optimize magnetic flux, resulting in consistent and reliable actuation.
Installation and Compatibility
With its standardized mounting dimensions, the TDS-08A can be easily integrated into existing systems or new designs. Its electrical characteristics align with common control circuits, simplifying the implementation process.
For detailed specifications and integration guidelines, please refer to the manufacturer’s datasheet or contact technical support.
