The Spectrum Controls TSX Quantum 4-Channel Meter Proving Flowmeter (Model 140MPM20400SC) is a specialized module designed for precise flow measurement and meter proving applications within industrial automation systems. This module seamlessly integrates with Schneider Automation’s Series Quantum PLCs, offering high accuracy and reliability for flow monitoring tasks.

Key Features

• Four Input Channels: Accommodates connections from up to four flow meter devices, each individually configurable to suit specific input requirements.
• Versatile Input Compatibility: Supports both AC (50 mV to 75V peak) and DC (5V, 12V, 24V) input signals, ensuring compatibility with a wide range of flow meters.
• Pulse Fidelity Checking: Features redundant input channels for each primary input, enabling pulse fidelity verification through API Level B phase, sequence, count, and frequency monitoring.
• Pulse Interpolation: Utilizes Double Chronometry Pulse Interpolation, providing resolution up to four decimal places, essential for short-run prover testing.
• High-Speed Input Processing: Offers an input filter frequency up to 50 kHz, suitable for high-speed flow measurement applications.
• Programmable Scaling Factors: Allows user-defined K, M, and R factors for precise scaling and calibration of flow measurements.
• Rapid Update Rate: Achieves a channel update time of 1 ms per channel, ensuring timely data acquisition and processing.
• Comprehensive Diagnostic Indicators: Equipped with LED indicators to display operating and fault statuses, facilitating efficient troubleshooting and maintenance.

Installation and Configuration

The 140MPM20400SC module is designed for straightforward installation within Quantum PLC racks. It communicates with the PLC and receives power through the backplane, eliminating the need for external power supplies. Configuration is managed via software, allowing users to set input ranges, scaling factors, and operational modes to match specific application requirements.

Applications

This module is ideal for industries requiring precise flow measurement and meter proving, such as oil and gas, water treatment, and chemical processing. Its advanced features ensure accurate flow data collection, essential for process control and regulatory compliance.

By integrating the Spectrum Controls TSX Quantum 4-Channel Meter Proving Flowmeter into your automation system, you enhance the accuracy and reliability of flow measurements, contributing to improved operational efficiency and product quality.
