SMC VQ1401N-51 5 Port Plug-In Valve

The SMC VQ1401N-51 is a high-performance 5-port solenoid valve designed for applications requiring rapid response times, frequent operation, and consistent performance. Its compact and innovative design ensures efficient operation and easy maintenance.

Key Features

• Actuation Type: 3-position exhaust center
• Seal Type: Rubber seal
• Function: Negative common (DC)
• Coil Voltage: 24VDC
• Manual Override: Non-locking push style (tool required)
• Light/Surge Suppressor: Integrated

Specifications

• Fluid Compatibility: Air and inert gases
• Operating Pressure Range: 0.1 MPa to 0.7 MPa
• Ambient and Fluid Temperature Range: -10°C to 50°C
• Effective Area: 5.4 mm² (Cv: 0.3)
• Response Time: 25 ms or less

Design and Installation

The VQ1401N-51 features a space-saving design with solenoid and fittings positioned on one side, allowing for flexible three-directional mounting. Its one-clamp structure facilitates easy valve replacement without the need to disassemble the entire manifold. Built-in one-touch fittings simplify the piping process, reducing installation time and labor.

Applications

This valve is ideal for industrial automation systems, pneumatic control circuits, and other applications where high-speed, reliable valve operation is essential. Its robust construction and efficient design make it suitable for various industrial environments.

For more detailed information, refer to the manufacturer’s specifications and documentation.
