Siemens 3 Pole 15A Circuit Breaker QP315

Siemens 3 Pole 15A Circuit Breaker QP315

The Siemens QP315 is a 15-amp, 3-pole circuit breaker designed for reliable protection in residential and commercial electrical systems. As part of Siemens’ QP series, this breaker ensures efficient management of electrical circuits, safeguarding against overloads and short circuits.

Key Features

• Amperage and Poles: Rated at 15 amps with a 3-pole configuration, suitable for three-phase electrical systems.
• Voltage Rating: Operates at 240 volts AC, accommodating standard electrical requirements.
• Interrupting Capacity: Offers a 10,000 ampere interrupting rating (AIC) at 240V, ensuring robust protection against high fault currents.
• Trip Mechanism: Utilizes a thermal-magnetic trip unit, providing both long-time and instantaneous protection.
• Mounting Type: Features a plug-in design for straightforward installation in compatible Siemens load centers.
• Wire Compatibility: Accepts wire sizes ranging from #14 to #6 AWG for both copper and aluminum conductors.
• Certifications: UL Listed, meeting industry standards for safety and performance.

Applications

The Siemens QP315 circuit breaker is ideal for use in Siemens 3-phase load centers, providing manual control to energize and de-energize circuits. Its design ensures compatibility with Siemens PL and ES series load centers, making it a versatile choice for various electrical distribution applications.

Dimensions

• Width: 4 inches
• Depth: 12.8 inches
• Height: 3.4 inches

These dimensions facilitate easy integration into standard electrical panels, ensuring a compact and efficient setup.

Conclusion

The Siemens QP315 3 Pole 15A Circuit Breaker combines safety, reliability, and ease of installation, making it a trusted component for managing electrical circuits in both residential and commercial settings.
