Rexroth Bosch KSM02.1B-071C-24N-S1-HP0-ET-L3-D7-NN-FW Servo Drive R911369140
The Rexroth Bosch KSM02.1B-071C-24N-S1-HP0-ET-L3-D7-NN-FW Servo Drive, part number R911369140, is a motor-integrated servo drive from the IndraDrive Mi series. This advanced unit combines a synchronous servo motor with an integrated inverter and control electronics, offering a compact and efficient solution for various automation applications.
Key Features
- Integrated Design: Combines motor and drive electronics into a single unit, reducing space requirements and simplifying installation.
- Power Range: Delivers an output power of 1,320 Watts, suitable for demanding applications.
- Voltage Compatibility: Operates with a DC supply voltage of 750 Volts, ensuring compatibility with standard industrial power systems.
- Cooling Method: Utilizes natural convection cooling, eliminating the need for additional cooling systems and enhancing reliability.
- Communication Interface: Equipped with a Multi-Ethernet interface, supporting various communication protocols for seamless integration into diverse control systems.
- Safety Features: Includes Safe Torque Off (STO) functionality, providing an essential safety mechanism to prevent unintended motor operation.
- Environmental Protection: Designed with an IP65-rated enclosure, offering robust protection against dust and water ingress, making it suitable for harsh industrial environments.
Technical Specifications
- Size: 071
- Length: C
- Motor Winding Code: 24N
- Shaft Style: Keyway and Sealing Ring
- Shaft End Type: Cylindrical (DIN 748)
- Centering Hole: DSM10 (DIN 332)
- Key Dimensions: 10 x 8 x 5 mm
- Feedback Type: Optical Encoder
- Holding Brake: Optional
- Electrical Connector: Hybrid
- Operational Temperature Range: 0 to 40 Degrees Celsius
The KSM02.1B-071C-24N-S1-HP0-ET-L3-D7-NN-FW Servo Drive is engineered to meet the rigorous demands of modern automation systems, providing a reliable and efficient solution for motion control applications.
