Ohmite Rheostat 50W 800 Ohm Model J RJS800
The Ohmite RJS800 is a high-quality wirewound rheostat designed for applications requiring precise resistance control. With a power rating of 50 watts and a resistance of 800 ohms, this rheostat is suitable for various industrial and electronic applications.
Key Features
- Resistance: 800 ohms
- Power Rating: 50 watts
- Tolerance: ±10%
- Rotation: 300°
- Number of Turns: 1.0
- Taper: Linear
- Resistive Material: Wirewound
- Termination Style: Solder Lug
- Actuator Type: Flatted
- Actuator Dimensions: 0.875″ (22.23mm) length, 0.250″ (6.35mm) diameter
- Bushing Thread: 3/8-32
- Mounting Type: Panel Mount
- Body Size: 2.310″ (58.67mm) diameter
Applications
The RJS800 rheostat is ideal for use in motor speed controls, light dimmers, and other equipment requiring convenient variable resistance settings. Its robust construction ensures smooth and reliable operation over extended periods.
Construction
Featuring a ceramic body with high-grade resistance alloy windings and a vitreous enamel coating, the RJS800 is built for durability. It includes a metal spring contact arm and solder-coated terminals, ensuring consistent performance in demanding environments.
Ordering Information
The Ohmite RJS800 is available for purchase through authorized distributors. Please note that lead times may vary, and it’s advisable to check current stock levels and availability.
