Murray Siemens 60A Type 3R Circuit Breaker Enclosure LW002GR
The Murray Siemens LW002GR is a robust 60-amp, single-phase, main lug load center designed for outdoor applications. Encased in a NEMA 3R-rated enclosure, it offers reliable protection against environmental elements, making it ideal for various outdoor electrical installations.
Key Features
- Amperage and Voltage Rating: 60A at 120/240VAC, suitable for single-phase systems.
- Configuration: Accommodates 2 spaces and up to 4 circuits, providing flexibility for various circuit configurations.
- Construction: Features a one-piece plated aluminum bus bar for enhanced conductivity and durability.
- Enclosure: NEMA 3R-rated for outdoor use, offering protection against rain and environmental hazards.
- Mounting: Designed for surface mounting, facilitating straightforward installation.
- Dimensions: Measures 8-1/4 inches in length, 5-3/8 inches in width, and 4-1/2 inches in depth, making it suitable for narrow stud applications.
- Compliance: UL Listed, ensuring adherence to safety and performance standards.
Additional Information
The LW002GR is equipped with factory-installed feed-through lugs and is compatible with MP-T, MP-HT, and MP-MT circuit breakers. Its design eliminates the need for notching required by standard load centers, simplifying the installation process. This load center is particularly suitable for applications where line voltage exceeds 120V to ground and is ideal for narrow stud installations.
For optimal performance and safety, ensure that the installation complies with all applicable electrical codes and standards.
