The Gould ITE Q120 is a single-pole, 20-amp circuit breaker designed for reliable electrical protection in residential and light commercial applications.
Key Features
- Amperage Rating: 20 Amps
- Voltage Rating: 120/240 Volts AC
- Interrupting Capacity: 10,000 Amps at 120 Volts AC
- Mounting Type: Plug-In
- Terminal Connection: Load Lug
- Wire Size Compatibility: 14 to 6 AWG (Copper/Aluminum)
- Certifications: UL Listed, CSA Certified
Design and Compatibility
The Q120 circuit breaker features a compact design with dimensions of approximately 3 inches in height, 1 inch in width, and 3 inches in depth. Its plug-in mounting style ensures straightforward installation and compatibility with various load centers. The breaker is equipped with a thermal-magnetic trip mechanism, providing both long-time and instantaneous protection against overloads and short circuits.
Applications
Ideal for electrical distribution systems, the Gould ITE Q120 is suitable for use in Siemens EQ, Siemens Ultimate, ITE, and Gould load centers or meter combinations. Its 20-amp capacity makes it appropriate for protecting circuits in residential and light commercial settings.
Safety and Compliance
This circuit breaker meets UL 489 and CSA C22.2 standards, ensuring adherence to safety and performance requirements. Its 10 kA interrupting rating at 120 volts AC provides robust protection against electrical faults.
In summary, the Gould ITE Q120 1-Pole 20A Circuit Breaker offers dependable circuit protection with easy installation, making it a practical choice for various electrical distribution needs.
