Flex-A-Seal Style 17 Single Spring “O-Ring” Style SK1017

The Flex-A-Seal Style 17 Single Spring “O-Ring” Style SK1017 is a robust mechanical seal engineered for efficient and reliable performance in various pump applications.

Design and Functionality

Featuring a single spring design, the Style 17 ensures consistent contact between sealing faces, effectively transmitting drive evenly around the rotary face’s full circumference. This is achieved through specially designed spring ends that provide an interference fit, enhancing grip as the shaft rotates. The compression spring is wound in either right or left-hand orientation, depending on shaft rotation.

Key Features

• Non-clogging design for enhanced durability.
• Simplified assembly process.
• Accommodates greater axial movement.
• Unbalanced design, ideal for low-pressure applications.
• Available in both inch and metric sizes.
• Standard components made from 316 stainless steel, with optional materials like Monel™ and Hastelloy® C276.
• Variety of face materials, including carbon, nickel-bound tungsten carbide, silicon carbide, and bronze.
• Cartridge design available as Mechanical Seal Style 57.

Specifications

• Maximum Temperature: 400°F (204°C)
• Maximum Pressure: 150 PSI (10 bar)
• Maximum Speed: 4500 FPM (22 m/sec)

Please note that the maximum temperature, pressure, and speed indicate operating extremes independently and do not imply the seal will function at these extremes simultaneously. For specific application requirements, it is advisable to consult with Flex-A-Seal directly.

The Flex-A-Seal Style 17 Single Spring “O-Ring” Style SK1017 is a dependable solution for maintaining optimal pump performance, offering durability and adaptability across various industrial settings.
