Dodge SCM 1-1/2″ 2 Bolt Pillow Block Bearing P2B-SCM-108

Dodge P2B-SCM-108 1-1/2″ 2-Bolt Pillow Block Bearing

The Dodge P2B-SCM-108 is a robust 2-bolt pillow block bearing designed for medium-duty applications. Featuring a 1-1/2 inch bore diameter, this bearing unit ensures reliable performance in various industrial settings.

Key Features

• Bore Diameter: 1-1/2 inches
• Housing Material: Durable cast iron construction
• Locking Mechanism: Set screw for secure shaft attachment
• Seal Type: Single lip contact seal to protect against contaminants
• Lubrication: Pre-lubricated with Unirex N2 grease for optimal performance
• Dynamic Load Capacity: 7,891 lbf
• Static Load Capacity: 4,906 lbf
• Maximum Speed: Up to 5,000 rpm

Dimensions

• Base to Bore Centerline: 2.125 inches
• Bore Length: 1.94 inches
• Bolt Center-to-Center Length: Adjustable between 5.5 to 6.19 inches

Applications

Ideal for general-purpose applications, the Dodge P2B-SCM-108 pillow block bearing is commonly used in conveyors, mechanical drives, and other industrial machinery requiring reliable shaft support and alignment.

With its solid cast iron housing and precision-engineered ball bearing insert, the P2B-SCM-108 offers durability and performance for a wide range of industrial applications.
