Clarostat 140-6738 100Ohm Potentiometer RA20LASB101A

Clarostat 140-6738 100 Ohm Potentiometer RA20LASB101A

The Clarostat 140-6738, also known as the RA20LASB101A, is a high-quality 100 Ohm wirewound potentiometer designed for precision control in various electronic applications. This single-turn rotary potentiometer offers reliable performance and durability, making it suitable for both industrial and commercial use.

Key Features

• Resistance Value: 100 Ohms
• Power Rating: 2 Watts
• Voltage Rating: 500 VDC
• Resistance Tolerance: ±10%
• Taper: Linear
• Number of Turns: Single-turn
• Termination Style: Solder lugs
• Mounting Style: Panel mount
• Operating Temperature Range: -55°C to +120°C

Physical Dimensions

• Body Diameter: 1.125 inches (28.58 mm)
• Body Height: 1.22 inches (30.99 mm)
• Shaft Diameter: 0.25 inches (6.35 mm)
• Shaft Length: 0.5 inches (12.7 mm)
• Bushing Length: 0.375 inches (9.5 mm)

The RA20LASB101A potentiometer is engineered to meet stringent performance standards, ensuring consistent and accurate adjustments in electronic circuits. Its robust construction and precise specifications make it an ideal choice for applications requiring dependable variable resistance control.
