Banner SME312CVQD Mini Beam Expert 53702

Banner SME312CVQD Mini-Beam Expert 53702

The Banner SME312CVQD Mini-Beam Expert 53702 is a compact, self-contained photoelectric sensor designed for precise object detection in industrial environments. Utilizing a visible red LED with a wavelength of 650 nm, this sensor operates in convergent mode, focusing on a 1.3 mm spot at a distance of 16 mm from the lens surface.

Key Features

• Convergent Sensing Mode: Ensures accurate detection of small objects within a 16 mm range.
• Visible Red LED: Provides a clear, 650 nm light source for reliable sensing.
• Push-Button TEACH Mode: Simplifies sensitivity adjustments and output programming without the need for manual calibration.
• Bipolar Outputs: Offers both NPN and PNP outputs, accommodating various control systems.
• Quick-Disconnect Connector: Features a 5-pin Euro-style M12 integral QD for easy installation and maintenance.
• Durable Housing: Constructed with a thermoplastic enclosure rated IP67 and NEMA 4X, ensuring resistance to dust and water ingress.
• LED Indicators: Includes status indicators for received signal strength, power on, and output state, facilitating straightforward monitoring.

Specifications

• Supply Voltage: 10-30 V DC
• Output Response Time: 0.5 ms
• Operating Temperature Range: -20°C to 70°C
• Repeatability: 100 µs
• Lens Material: Acrylic
• Adjustments: Teach Button
• Barrel Diameter: 18 mm

The SME312CVQD is engineered for applications requiring precise and reliable object detection, making it suitable for various industrial automation tasks.
