Atkomatic 3/4″ Pipe 1″ Port 2-Way Solenoid Valve US-500

Atkomatic 3/4″ Pipe 1″ Port 2-Way Solenoid Valve US-500

The Atkomatic US-500 is a robust 2-way solenoid valve engineered for efficient control of various fluids, including gases, water, oil, and steam. Designed with a 3/4-inch pipe size and a 1-inch port, this valve ensures optimal flow capacity and reliable performance in demanding industrial applications.

Key Features

• Durable Construction: Crafted from high-quality materials, the US-500 offers exceptional corrosion resistance and longevity, making it suitable for harsh environments.
• Pilot-Operated Design: This valve utilizes a pilot-piston mechanism, requiring a minimum pressure differential of 5 psig (0.4 bar) for operation, ensuring efficient performance in systems with consistent flow.
• Versatile Application: Capable of handling a wide range of fluids, the US-500 is ideal for controlling the flow of air, gases, liquids, hydraulic fluids, steam, and cryogenic fluids.
• Temperature Resilience: Engineered to operate effectively across a broad temperature spectrum, accommodating fluid temperatures from -423°F to +500°F (-253°C to +260°C).
• High Pressure Handling: Designed to withstand pressures up to 500 psig (34.5 bar), ensuring reliable operation under high-pressure conditions.

Specifications

• Pipe Size: 3/4 inch
• Port Size: 1 inch
• Valve Type: 2-Way Solenoid Valve
• Operation: Pilot-Operated
• Pressure Range: 5 to 500 psig (0.4 to 34.5 bar)
• Temperature Range: -423°F to +500°F (-253°C to +260°C)
• Body Material: Bronze
• Flow Coefficient (Cv): Varies based on specific model configurations

The Atkomatic US-500 solenoid valve is a reliable and durable solution for precise fluid control in industrial settings, offering versatility and performance to meet the demands of various applications.
