Allen Bradley VPL-B0753F-PJ12AS /A Kinetix VP Low Inertia Servo Motor

Allen-Bradley VPL-B0753F-PJ12AS Kinetix VP Low Inertia Servo Motor

The Allen-Bradley VPL-B0753F-PJ12AS is a high-performance servo motor designed to deliver precise motion control in demanding industrial applications. As part of the Kinetix VP Low Inertia series, this motor offers exceptional responsiveness and efficiency, making it ideal for tasks requiring rapid acceleration and deceleration.

Key Features

• Voltage and Frame Size: Operates at 480V AC with a 75mm bolt circle frame size, providing a compact yet powerful solution for various automation needs.
• Magnet Stacks: Equipped with three magnet stacks, enhancing torque production and overall motor performance.
• Rated Speed: Features an F winding configuration, supporting a rated speed of 4500 RPM, suitable for high-speed operations.
• Feedback System: Incorporates an 18-bit single-turn and 12-bit multi-turn digital high-resolution encoder, ensuring precise position and speed feedback for accurate control.
• Shaft Design: Comes with a keyed shaft extension, facilitating secure and reliable mechanical connections.
• Connectors: Utilizes a single SpeedTec DIN connector, simplifying installation and maintenance processes.
• Holding Brake: Designed without a holding brake, suitable for applications where such functionality is not required.
• Mounting and Sealing: Features an IEC metric mounting flange and is fitted with an IP66 shaft seal, offering robust protection against dust and water ingress.

Applications

The VPL-B0753F-PJ12AS servo motor is well-suited for a wide range of industrial applications, including but not limited to:

• Packaging machinery
• Material handling systems
• Conveyor systems
• Automated assembly lines
• Printing and converting equipment

Its low inertia design ensures rapid response times, making it particularly effective in applications requiring quick and precise movements.

Technical Specifications

• Voltage Class: 480V AC
• Frame Size: 75mm bolt circle
• Magnet Stacks: 3
• Rated Speed: 4500 RPM
• Feedback Type: 18-bit single-turn and 12-bit multi-turn digital high-resolution encoder
• Shaft Extension: Keyed shaft
• Connectors: Single SpeedTec DIN connector
• Holding Brake: None
• Mounting: IEC metric mounting flange
• Sealing: IP66 shaft seal fitted

For detailed technical information and installation guidelines, please refer to the official product documentation.
