Allen-Bradley Type P AC Relay 700-P400A1 /B

The Allen-Bradley 700-P400A1 /B is a robust industrial relay designed for demanding applications requiring reliable switching capabilities. This relay is part of the Bulletin 700 series, known for its durability and performance in control systems.

Key Features

• Contact Configuration: Equipped with four normally open (N.O.) contacts, facilitating straightforward integration into various control circuits.
• Coil Voltage: Operates efficiently at 110V AC for 50 Hz and 115-120V AC for 60 Hz, ensuring compatibility with standard power supplies.
• Current Rating: Supports a continuous current rating of 10A at 600V AC, suitable for handling substantial electrical loads.
• Mounting Options: Versatile mounting capabilities allow for panel, strip mount, or DIN rail installations, with horizontal DIN rail mounting recommended for optimal performance.
• Contact Material: Constructed with silver nickel contacts, providing excellent conductivity and resistance to wear.
• Wire Size Compatibility: Accommodates wire sizes ranging from #18 AWG to (2) #12 AWG per UL/CSA standards, offering flexibility in wiring configurations.

Environmental Specifications

• Operating Temperature: Designed to function reliably within a temperature range of -20°C to 40°C, suitable for various industrial environments.
• Storage Temperature: Can be stored safely at temperatures as low as -40°C, ensuring longevity and readiness for deployment.

Certifications and Standards

The 700-P400A1 /B relay meets multiple international standards, including CE, CSA, CUL, KC, MARINE, and UL certifications, affirming its quality and safety for global applications.

Applications

This relay is ideal for machine tool operations and other heavy-duty industrial applications where dependable control and switching are paramount. Its robust design and versatile mounting options make it a valuable component in complex control systems.

For detailed technical drawings and additional documentation, please refer to the manufacturer’s resources.
