Allen Bradley Inverter Duty AC Servo Motor VPL-B0633T-PJ14AA

The Allen-Bradley VPL-B0633T-PJ14AA is a high-performance, low-inertia servo motor engineered for precision motion control applications.

Key Features

• Voltage and Frame Size: Operates at 480V AC with a 63mm bolt circle frame size.
• Magnet Stacks: Equipped with three magnet stacks to enhance torque and responsiveness.
• Rated Speed: Achieves a rated speed of 6750 RPM, suitable for high-speed operations.
• Feedback System: Features an 18-bit single-turn and 12-bit multi-turn digital high-resolution encoder for accurate position feedback.
• Shaft Configuration: Comes with a keyed shaft for secure mechanical coupling.
• Connectivity: Utilizes a single SpeedTec right-angle DIN connector for streamlined installation.
• Holding Brake: Incorporates a 24V DC holding brake to maintain position during power loss or system shutdowns.
• Mounting: Designed with an IEC metric mounting flange for compatibility with various mounting configurations.

Applications

This servo motor is ideal for applications requiring rapid acceleration and deceleration, precise positioning, and high-speed performance, such as in packaging machinery, robotics, and automated assembly lines.

Additional Information

The VPL-B0633T-PJ14AA is part of Allen-Bradley’s Kinetix VP Low Inertia Servo Motor series, known for delivering dynamic performance and efficient system sizing. ([rockwellautomation.com](https://www.rockwellautomation.com/en-us/products/details.VPL-B0633T-PJ14AA.html?utm_source=openai))

For detailed technical specifications and installation guidelines, refer to the product’s cut sheet. ([configurator.rockwellautomation.com](https://configurator.rockwellautomation.com/api/Product/vpl-b0633t-pj14aa/cutsheet?utm_source=openai))
