Allen Bradley 845H-SJDZ25EGY2C /B 8-24VDC

Allen-Bradley 845H-SJDZ25EGY2C Incremental Encoder

The Allen-Bradley 845H-SJDZ25EGY2C is a high-performance incremental encoder designed to provide precise position and speed feedback in industrial automation systems. This encoder is part of the 845H series, known for its reliability and accuracy in demanding applications.

Key Features

• Power Supply: Operates on an unregulated 8-24V DC power source, ensuring compatibility with various industrial power systems.
• Shaft Options: Equipped with a 3/8-inch diameter shaft, facilitating easy integration into existing setups.
• Output Configuration: Features an NPN open collector output with a maximum of 24V DC, suitable for interfacing with a wide range of control systems.
• Resolution: Offers a resolution of 300 pulses per revolution (PPR), providing accurate position feedback for precise control applications.
• Connector Type: Comes with a radial (side) connector, allowing for convenient and secure connections in various mounting configurations.

Applications

The 845H-SJDZ25EGY2C encoder is ideal for applications requiring accurate position and speed measurement, such as:

• Conveyor systems
• Robotic arms
• Packaging machinery
• Material handling equipment

Its robust design and reliable performance make it a suitable choice for harsh industrial environments.

Additional Information

For detailed installation instructions and technical specifications, please refer to the official Allen-Bradley documentation. Ensure proper handling and installation to maintain the encoder’s performance and longevity.
