Allen Bradley 800M-XA /B 2 Position Selector Switch 800MS-HX2B /A

Allen-Bradley 800M-XA /B 2-Position Selector Switch 800MS-HX2B /A

The Allen-Bradley 800M-XA /B 2-Position Selector Switch, catalog number 800MS-HX2B /A, is a robust and reliable component designed for industrial control applications. This selector switch offers precise control with its two maintained positions, allowing operators to select between two distinct states in control circuits.

Key Features

• Operator Type: 2-position selector switch
• Operator Function: Maintained positions
• Cam Code: B Cam
• Contact Configuration: No contact cartridge
• Termination Type: Stab terminals
• Hole Diameter: 22.5 mm
• Operator Mechanical Design Life: Minimum of 200,000 cycles
• Enclosure Compatibility: Type 13, IEC I44 IP65 oiltight
• Shock Resistance: 100 G
• Vibration Resistance: 10 G

Design and Construction

The 800MS-HX2B /A selector switch is constructed with durable materials suitable for demanding industrial environments. Its design ensures longevity and consistent performance, with an operator mechanical design life of at least 200,000 cycles. The switch is compatible with enclosures rated Type 13 and IEC I44 IP65, providing protection against dust and water ingress.

Electrical Specifications

• Contact Block Thermal Current Rating: 10 A
• Contact Block Utilization Category (AC): 300V @ 150V AC, 0.15A @ 8VA (logic reed)
• Contact Block Utilization Category (DC): 30V @ 0.06A, 1.8VA (logic reed)
• Contact Block Operational Voltage, Max: AC 300V

Environmental Specifications

• Operating Temperature: 0°C
• Humidity: 50% at 40°C (104°F)
• Storage Temperature: -40°C

Certifications

The 800MS-HX2B /A selector switch meets various industry standards and certifications, ensuring compliance with safety and performance requirements.

For more detailed information and technical documentation, please refer to the product’s technical data sheet.
