Allen Bradley 592-A2NF /A Overload Relay W/ Motor Starter Size 5 509-FOD-A2N /L

Allen Bradley 592-A2NF /A Overload Relay with Motor Starter Size 5 509-FOD-A2N /L

The Allen Bradley 592-A2NF /A Overload Relay, paired with the Motor Starter Size 5 model 509-FOD-A2N /L, offers a robust solution for controlling and protecting large three-phase motors. This combination is designed to ensure reliable motor operation and safeguard against overload conditions.

Key Features

• Overload Relay (592-A2NF /A): This solid-state overload relay provides advanced motor protection with a current range of 96 to 300 amps. It features a manual reset and offers phase loss protection, enhancing motor safety and performance.
• Motor Starter (509-FOD-A2N /L): The NEMA Size 5 non-reversing starter is suitable for three-phase applications. It operates at a control voltage of 115/120V AC and includes an E100 solid-state overload relay with a current range of 60 to 300 amps.

Technical Specifications

• Continuous Current Rating: 270 A
• Service Limit Current Rating: 311 A
• Maximum Horsepower Rating (Three-Phase): 150 HP
• Operating Temperature Range: -13°F to +131°F (-25°C to +55°C)
• Altitude: Up to 10,000 feet before derating
• Enclosure Type: Open Type Without Enclosure

Applications

This combination is ideal for industrial applications requiring reliable motor control and protection, such as:

• Pumps
• Compressors
• Heavy machinery
• Motor control centers (MCCs)

By integrating the Allen Bradley 592-A2NF /A Overload Relay with the 509-FOD-A2N /L Motor Starter, users can achieve enhanced motor performance and protection in demanding industrial environments.
