Allen-Bradley 500L-AOD92/B 15/20A Lighting Contactor
The Allen-Bradley 500L-AOD92/B is a NEMA Size 0 electrically held lighting contactor, designed for efficient control of lighting and non-motor loads. This open-style contactor is suitable for various industrial and commercial applications requiring reliable switching capabilities.
Key Features
- Maximum Ampere Rating: 15A for tungsten lamp loads and 20A for non-motor, resistive heating, ballast, and discharge lighting loads.
- Coil Voltage: Operates at 115-120V, 60Hz, ensuring compatibility with standard power supplies.
- Pole Configuration: Equipped with 2 power poles, facilitating effective control of connected circuits.
- Enclosure Type: Open-style design, allowing for easy integration into existing systems.
- Phase Compatibility: Suitable for three-phase systems, enhancing versatility in various applications.
Applications
The 500L-AOD92/B is ideal for controlling lighting circuits in commercial buildings, industrial facilities, and other environments where efficient management of lighting loads is essential. Its robust design ensures reliable performance in demanding conditions.
Dimensions and Weight
- Height: 17.805 cm
- Width: 10.592 cm
- Length: 12.7 cm
- Weight: 1.366 kg
These compact dimensions facilitate easy installation and integration into existing control panels.
Additional Information
The 500L-AOD92/B is part of Allen-Bradley’s NEMA lighting contactor series, known for durability and high performance. It is designed to meet the needs of various lighting control applications, providing a reliable solution for managing electrical loads.
For detailed technical specifications and installation guidelines, refer to the product’s technical data sheet.
