Allen Bradley 500-BOD92 /B

Allen-Bradley 500-BOD92/B NEMA Size 1 Contactor

The Allen-Bradley 500-BOD92/B is a NEMA Size 1 contactor designed for efficient control of electrical circuits. This model features an open enclosure and operates with a 115-120V 60Hz coil voltage. It is equipped with two power poles, each capable of handling up to 30 amperes, making it suitable for various non-motor and lighting load applications.

Key Features

• Enclosure Type: Open
• Coil Voltage: 115-120V 60Hz
• Pole Configuration: 2 Power Poles
• Maximum Ampere Rating: 30A for non-motor and lighting loads
• Continuous Current: 27A
• Service Limit Current Rating: 32A
• Heat Dissipation: 5.9W
• Wire Size for Power Terminals: #14 to #8 AWG
• Operating Volt-Amperes Burden: Sealed: 29VA at 60Hz
• Mechanical Life Operations: 10 million cycles
• Average Operating Time: Pick-up: 22 ms; Drop-out: 14 ms
• Power Contact Material: Silver Alloy
• Auxiliary Contact Material: Silver
• Operating Position: Vertical
• Corrosion Resistance: All metal parts are treated for corrosion resistance

Dimensions and Weight

• Width: 90.5 mm
• Height: 152 mm
• Depth: 113 mm
• Shipping Weight: Approximately 1.4 kg (3 lb)

For detailed technical information, refer to the technical data publication 500-TD013.
