The Allen-Bradley 20-HIM-A6 is a Human Interface Module (HIM) designed to enhance the operation and monitoring of PowerFlex AC drives. Featuring a backlit LCD display and a full numeric keypad, this module facilitates straightforward navigation and data entry, making it an essential tool for efficient drive management.
Key Features
- Backlit LCD Display: Provides clear visibility of parameters and status information, even in low-light conditions.
- Full Numeric Keypad: Enables easy input and adjustment of drive settings.
- Remote Mounting Capability: Includes mounting bezel, gasket, and cable for convenient panel installation, allowing external access without opening the drive enclosure.
- CopyCat Functionality: Allows for quick uploading and downloading of drive parameters, streamlining the configuration process across multiple drives.
- Multi-Language Support: Accommodates diverse user needs with multiple language options.
- Compatibility: Supports a wide range of PowerFlex drives, including the 4, 40, 400, 70, 700, and 750-Series.
- Status Indicators: LEDs provide immediate feedback on operating conditions and alert statuses.
Technical Specifications
- Catalog Number: 20-HIM-A6
- Display Type: Backlit LCD, 7-line
- Keypad: Full numeric with navigation keys
- Mounting: Remote panel mount with standard 4-hole pattern
- Power Source: Supplied from the connected drive
- Interface: Drive Serial Interface (DSI)
- Dimensions (HxWxD): Approximately 97 x 107 x 37 mm
- Environmental Rating: NEMA 1 / IP30 front when mounted
- Operating Temperature: 0 to 50 °C
- Certifications: UL, CE, RoHS
Applications
- Drive Control and Monitoring: Facilitates real-time adjustments and oversight of drive operations.
- Setup and Parameter Programming: Simplifies the configuration process for new installations or system updates.
- OEM Equipment Panels: Ideal for integration into original equipment manufacturer panels, providing user-friendly control interfaces.
- Drive Commissioning and Maintenance: Assists in the efficient commissioning of drives and ongoing maintenance tasks.
Why Choose the 20-HIM-A6?
- Intuitive Interface: Offers real-time status feedback, enhancing user experience and operational efficiency.
- Parameter Cloning: Reduces downtime by enabling quick duplication of drive settings across multiple units.
- External Access: Allows for safer adjustments without the need to open drive enclosures.
- Broad Compatibility: Supports a diverse range of PowerFlex drive models, ensuring versatility in various applications.
- Durable Construction: Built to withstand industrial environments, ensuring long-term reliability.
The Allen-Bradley 20-HIM-A6 HIM is a robust and user-friendly solution for enhancing the control and monitoring capabilities of PowerFlex AC drives, making it a valuable addition to any industrial automation setup.
