Allen Bradley 2090-CSWM1DE-14AA05 /A Cable Kinetix 5m Smartlink Single Non-Flex

The Allen-Bradley 2090-CSWM1DE-14AA05 is a 5-meter Kinetix® single cable designed for seamless integration with Kinetix 5700 servo drives. This standard, non-flexible cable combines motor power and feedback signals into a single, efficient connection.

Key Features

• Drive-End Connector: Optimized for Kinetix 5700, featuring a drive-end connector kit.
• Motor-End Connector: Equipped with a Single SpeedTec DIN connector for secure and reliable motor connections.
• Wire Gauge: Utilizes 14 AWG tinned copper conductors, ensuring optimal electrical performance.
• Cable Style: Constructed with a Thermoplastic Elastomer (TPE) jacket, offering durability and resistance to mechanical and chemical wear.
• Functionality: Designed to transmit both motor power and digital feedback signals, streamlining system wiring.

Technical Specifications

• Outer Diameter: Approximately 17 mm.
• Number of Cores: 8, including four power and two feedback conductors.
• Nominal Voltage: Rated at 1000 V.
• Static Bend Radius: Standard non-flex and continuous flex: 7 times the cable diameter.
• Maximum Conductor Temperature: 105°C.

Applications

This cable is ideal for applications requiring a robust and efficient connection between Kinetix 5700 drives and compatible motors. Its integrated design reduces wiring complexity and enhances system reliability.

By incorporating the Allen-Bradley 2090-CSWM1DE-14AA05 into your automation setup, you ensure a high-performance, durable, and streamlined solution for your motion control needs.
