Allen Bradley 16 Channel Current Input Module 1769-IF16C /A

Allen-Bradley 1769-IF16C 16-Channel Analog Current Input Module

The Allen-Bradley 1769-IF16C is a high-density analog current input module designed for integration with CompactLogix and MicroLogix 1500 controllers. It offers precise monitoring of process variables through its 16 single-ended input channels, making it ideal for various industrial applications.

Key Features

• Input Channels: 16 single-ended
• Input Signal Ranges: 0–20 mA and 4–20 mA
• Full-Scale Ranges: 0–21 mA and 3.2–21 mA
• Resolution: 16 bits (unipolar); 15 bits plus sign (bipolar)
• Converter Type: Sigma-Delta
• Input Impedance: 249 Ω
• Accuracy: ±0.5% full scale at 25°C (77°F)
• Common Mode Rejection: Greater than 60 dB at 50 and 60 Hz with the 16 Hz filter selected
• Isolation Voltage: 30V AC/30V DC working voltage (IEC Class 2 reinforced insulation)
• Power Consumption: 4.0 W maximum
• Backplane Current Draw: 190 mA at 5.1V DC; 70 mA at 24V DC
• Operating Temperature Range: 0°C to 60°C (32°F to 140°F)
• Dimensions: 118 mm (H) x 35 mm (W) x 87 mm (D) (4.65 in. x 1.38 in. x 3.43 in.)
• Mounting Options: DIN rail or panel mount

Applications

The 1769-IF16C module is suitable for a wide range of industrial applications, including:

• Industrial process control systems
• Sensor and transmitter signal monitoring
• OEM machines and skid units
• Compact I/O-based automation architectures
• Flow, level, temperature, and pressure measurement

Why Choose the 1769-IF16C?

• Compact and Scalable: Ideal for growing or space-limited systems
• Reliable Analog Monitoring: Designed for industrial current loop standards
• Easy Integration: Seamlessly works with Studio 5000 and RSLogix
• Efficient Wiring and Maintenance: Removable terminal blocks and status indicators
• Trusted Rockwell Automation Quality: Built for long-term reliability

The Allen-Bradley 1769-IF16C module provides a reliable and efficient solution for monitoring analog current signals in industrial environments, ensuring precise data acquisition and integration with existing control systems.
