Advanced Illumination LL2912 Linelight LL2912E-660

Advanced Illumination LL2912E-660 Line Light

The Advanced Illumination LL2912E-660 is a 3-inch LED line light engineered for precision in machine vision applications, particularly with line-scan cameras. Emitting light at a wavelength of 660nm (red), it ensures consistent and uniform illumination essential for high-quality imaging.

Key Features

• Compact Design: Measuring 3 inches in length, the LL2912E-660 is ideal for installations where space is limited.
• Versatile Lens Options: Available with various lenses to accommodate different working distances and line widths, enhancing adaptability across diverse applications.
• High Intensity Illumination: Provides 15mm of intense illumination, ensuring optimal performance in low-intensity, low-speed line scan scenarios.
• Multiple Wavelengths: While this model operates at 660nm, the LL2912 series offers options in red, green, blue, white, UV, and IR wavelengths to suit specific imaging requirements.
• Durable Construction: Built to withstand industrial environments, the LL2912E-660 operates reliably within a temperature range of 0 to 60°C.

Specifications

• Operating Voltage: 24V DC
• Current Consumption: 0.03A per 1.5 inches
• Weight: Approximately 290g
• Standard Cable Length: 1.5 meters (59 inches)
• Compliance: CE, RoHS, IEC 62471
• IP Rating: IP50
• Lumen Maintenance: L70 = 50,000 hours

Applications

The LL2912E-660 is ideally suited for:

• Low-intensity, low-speed line scan applications
• Precision imaging tasks requiring uniform red illumination
• Industrial environments where compact and reliable lighting solutions are essential

With its robust design and versatile features, the Advanced Illumination LL2912E-660 Line Light is a dependable choice for enhancing imaging performance in various machine vision applications.
