Allen-Bradley 2090-UXBB-DM15 Motor Feedback Breakout Board The Allen-Bradley 2090-UXBB-DM15 is a drive-mounted breakout board designed to facilitate motor feedback connections for Ultra3000 and Ultra5000 servo drives. This 15-pin connector interfaces seamlessly with the CN2 feedback port, ensuring efficient and reliable communication between the motor and drive system. Key Features Compatibility: Specifically engineered for Ultra3000 and Ultra5000 series drives, providing a direct and secure connection to the CN2 feedback connector. Design: The drive-mounted configuration allows for a compact and organized setup, reducing wiring complexity and enhancing system aesthetics. Connector Specifications: Equipped with a 15-pin D-sub male connector, ensuring a standardized and robust interface for motor feedback signals. Wire Accommodation: Supports wire sizes ranging from 30 to 16 AWG, offering flexibility in wiring choices to suit various application requirements. Installation Ease: Designed for straightforward installation with recommended torque settings of 0.40 N·m for mounting screws and 0.25 N·m for terminal screws, ensuring secure and stable connections. Technical Specifications Maximum Cable Diameter: 11.4 mm (0.45 in.) Recommended Wire Strip Length: 25 to 51 mm (1 to 2 in.) Mounting Screw Torque: 0.40 N·m (3.5 lb·in.) Terminal Screw Torque: 0.25 N·m (2.2 lb·in.) The 2090-UXBB-DM15 breakout board is an essential component for applications requiring precise motor feedback integration with Allen-Bradley’s Ultra3000 and Ultra5000 drives. Its design emphasizes ease of installation, reliable performance, and compatibility, making it a valuable addition to motion control systems.
