Westinghouse 3 Pole 3A Motor Circuit Protector Series C HMCP003A0C

Westinghouse 3 Pole 3A Motor Circuit Protector Series C HMCP003A0C

The Westinghouse HMCP003A0C is a high-performance motor circuit protector designed to provide reliable short-circuit protection for motor circuits. As part of the Series C lineup, this device ensures optimal safety and efficiency in industrial applications.

Key Features

• Amperage Rating: 3 Amperes
• Voltage Rating: 600 VAC / 250 VDC
• Number of Poles: 3
• Frame Size: F Frame
• Trip Type: Magnetic
• Magnetic Trip Range: 9 to 30 Amperes
• Series: Series C
• Terminal Material: Non-aluminum
• Connection Type: Line/Load Terminal
• Enclosure Type: NEMA 0

Product Specifications

• Product Length/Depth: 8 inches
• Product Height: 5 inches
• Product Width: 5 inches
• Product Weight: 4.5 lbs

Certifications

• UL Listed
• CSA Certified
• IEC 157-1

Additional Features

• Provides phase loss and phase unbalance protection to prevent severe equipment damage that can occur with a single phasing condition.
• Thermal memory prevents immediate restart after trip to allow the motor to cool down.
• High load alarm LED status indicator provides early warning of potential trip condition.

The Westinghouse HMCP003A0C is engineered to deliver precise and reliable protection for motor circuits, making it an essential component in maintaining the safety and efficiency of industrial motor applications.
