Overview The T8594 Long Weld Neck Flange is a high-pressure forged steel component designed for industrial applications requiring robust and reliable connections. With a pressure rating of 900 pounds per square inch (900LBS) and a nominal pipe size of 1.5 inches, this flange is engineered to meet the demands of high-pressure systems. Key Features Material: Constructed from high-quality forged steel, ensuring durability and resistance to high-pressure environments. Design: Features a long weld neck, providing a smooth transition from flange to pipe, which helps in reducing stress concentrations and enhancing the structural integrity of the connection. Pressure Rating: Rated for 900LBS, making it suitable for high-pressure applications. Size: Designed for pipes with a nominal diameter of 1.5 inches. Standards Compliance: Manufactured in accordance with ASME B16.5 standards, ensuring compatibility and reliability in industrial piping systems. Applications The T8594 Long Weld Neck Flange is ideal for use in industries such as oil and gas, petrochemical, power generation, and other sectors where high-pressure piping systems are prevalent. Its design and material composition make it suitable for environments requiring secure and leak-proof connections. Technical Specifications Outer Diameter (O): Approximately 7 inches (178 mm). Flange Thickness (C): Approximately 1.25 inches (31.8 mm). Hub Diameter at Bevel (A): Approximately 2.75 inches (69.9 mm). Diameter of Bore (B): Approximately 1.5 inches (38.1 mm). Length Through Hub (H): Approximately 9 inches (228.6 mm). Diameter of Bolt Circle (BC): Approximately 4.88 inches (123.8 mm). Number of Bolt Holes: 4. Diameter of Bolt Holes (d): Approximately 1.12 inches (28.5 mm). Advantages Enhanced Strength: The long weld neck design provides additional reinforcement, reducing the risk of deformation under high pressure. Improved Flow Characteristics: The smooth transition from flange to pipe minimizes turbulence and pressure drop. Leak-Proof Connection: The extended neck allows for a full penetration weld, ensuring a secure and leak-proof joint. Conclusion The T8594 Long Weld Neck Flange is a critical component for high-pressure piping systems, offering durability, reliability, and compliance with industry standards. Its design and material properties make it a preferred choice for engineers and professionals in various industrial sectors.
