SMC CDM2D25-50Z

SMC CDM2D25-50Z Pneumatic Cylinder

The SMC CDM2D25-50Z is a high-performance pneumatic cylinder from the CM2-Z series, designed to deliver precise and reliable linear motion in various industrial applications.

Key Features

• Bore Size: 25 mm
• Stroke Length: 50 mm
• Mounting Style: Double Clevis
• Cushion Type: Rubber Bumper
• Rod End Thread: Male
• Port Thread Standard: Rc
• Built-in Magnet: Facilitates auto-switch integration for precise position sensing

Design and Performance

Constructed with a round body design, the CDM2D25-50Z ensures durability and efficient performance. The built-in magnet allows for seamless installation of auto-switches, enhancing position detection capabilities. Rubber bumper cushioning minimizes impact at the end of the stroke, reducing noise and extending the cylinder’s lifespan.

Applications

This pneumatic cylinder is ideal for applications requiring precise linear motion, such as:

• Pick and place systems
• Clamping operations
• Positioning tasks
• Automated assembly lines

Additional Information

The CDM2D25-50Z is part of SMC’s CM2-Z series, known for its compact design and versatility. The double clevis mounting style offers flexibility in installation, accommodating various system configurations. The male rod end thread ensures compatibility with a wide range of fittings and accessories.

For optimal performance, ensure proper installation and maintenance as per SMC’s guidelines. The integration of auto-switches enhances the cylinder’s functionality, providing real-time feedback on position and movement.
