SMC Auto Switch D-H7PW

SMC Auto Switch D-H7PW

The SMC Auto Switch D-H7PW is a solid-state, PNP output auto switch designed for precise position detection in pneumatic systems. Its compact design and advanced features make it an ideal choice for various industrial automation applications.

Key Features

• 2-Color Indicator Light: Equipped with a red and green LED indicator, the D-H7PW provides clear visual feedback. The red LED illuminates when the switch is within the operating range, while the green LED indicates the proper operating position, ensuring accurate setup and monitoring.
• PNP Output Type: The 3-wire PNP configuration allows for seamless integration with compatible control systems, facilitating efficient signal processing.
• Wide Operating Voltage: Supports a power supply voltage range of 4.5 to 28 VDC, offering flexibility across various applications.
• High Load Capacity: Capable of handling load currents up to 80 mA, accommodating diverse load requirements.
• Low Internal Voltage Drop: Features an internal voltage drop of 0.8 V or less, ensuring minimal power loss during operation.
• Compact and Durable Design: With dimensions of 33.6 mm in length, 8 mm in width, and 11.5 mm in height, and weighing approximately 13 grams, the D-H7PW is designed for easy installation in space-constrained environments. Its robust construction ensures longevity and reliable performance.
• Environmental Resilience: Operates effectively within a temperature range of -10°C to +60°C, making it suitable for various industrial settings.
• Compliance and Standards: Conforms to CE standards and meets JIS C 0920 and IEC 529 regulations, ensuring adherence to international safety and performance standards.

Applications

The D-H7PW auto switch is ideal for applications requiring precise position sensing in pneumatic systems, such as automated manufacturing lines, assembly processes, and material handling systems. Its reliable performance enhances control and monitoring, leading to improved efficiency in automation processes.

By integrating the SMC D-H7PW auto switch into your pneumatic systems, you can achieve enhanced control and monitoring, leading to improved efficiency and reliability in your automation processes.
