Siemens Simatic ET 200SP Analog Input Module 6ES7 134-6GF00-0AA1

Siemens SIMATIC ET 200SP Analog Input Module 6ES7 134-6GF00-0AA1

The Siemens SIMATIC ET 200SP Analog Input Module 6ES7 134-6GF00-0AA1 is a high-performance component designed for precise analog signal acquisition in industrial automation systems. This module seamlessly integrates into the ET 200SP distributed I/O system, offering flexibility and efficiency for various applications.

Key Features

• Analog Inputs: Equipped with 8 single-ended analog input channels, supporting both 2-wire and 4-wire configurations.
• High Resolution: Delivers 16-bit resolution for accurate and reliable data acquisition.
• Compact Design: With a width of just 15 mm, it is ideal for installations where space is limited.
• Module Diagnostics: Incorporates comprehensive diagnostic functions to ensure operational reliability and facilitate quick troubleshooting.
• Compatibility: Designed for use with BU-type A0 and A1 BaseUnits, featuring a color code of CC01 for easy identification.

Technical Specifications

• Input Signal Types: Supports current measurements of 0 to 20 mA, -20 mA to +20 mA, and 4 mA to 20 mA.
• Input Resistance: 100 Ω for current inputs.
• Conversion Time: Typically 180 ms per channel, ensuring timely data processing.
• Power Supply: Operates within a voltage range of 19.2 V to 28.8 V DC, with a maximum current consumption of 25 mA (excluding sensor power supply).
• Operating Temperature: Suitable for environments ranging from -30°C to +60°C.
• Dimensions (W x H x D): 15 mm x 73 mm x 58 mm.
• Weight: Approximately 36 g.

Applications

This analog input module is ideal for:

• Process control systems requiring precise analog data acquisition.
• Integration with various sensors and actuators in industrial automation setups.
• OEM machinery and equipment needing compact and efficient I/O solutions.
• Systems utilizing the ET 200SP platform for modular and scalable automation architectures.

Why Choose the 6ES7 134-6GF00-0AA1?

• Precision: High-resolution inputs ensure accurate measurement and control.
• Space Efficiency: Its slim profile allows for high-density installations without compromising performance.
• Reliability: Built-in diagnostics enhance system uptime and facilitate maintenance.
• Flexibility: Supports multiple wiring configurations and integrates seamlessly with Siemens automation tools.

The Siemens SIMATIC ET 200SP Analog Input Module 6ES7 134-6GF00-0AA1 is a robust and versatile solution for demanding industrial applications, ensuring precise data acquisition and reliable performance in a compact form factor.
