Siemens 90A 3 Pole Definite Purpose Magnetic Contactor 42GE35AF106

Siemens 90A 3-Pole Definite Purpose Magnetic Contactor 42GE35AF106

The Siemens 42GE35AF106 is a robust 3-pole definite purpose magnetic contactor designed to handle demanding applications in HVAC systems, refrigeration, and electric heating. With a full load inductive current rating of 90 amperes and a resistive current rating of 120 amperes, this contactor ensures reliable performance in various industrial settings.

Key Features

• High Current Capacity: Supports up to 90A for inductive loads and 120A for resistive loads, accommodating substantial electrical demands.
• Versatile Coil Voltage: Operates with a 120V AC coil at 50/60 Hz, providing flexibility for different power systems.
• Multiple Horsepower Ratings: Capable of handling:
  • 15 HP at 240V AC (Single Phase)
  • 30 HP at 240V AC (Three Phase)
  • 50 HP at 480V AC (Three Phase)
  • 50 HP at 600V AC (Three Phase)
• Durable Construction: Features silver cadmium oxide contacts for enhanced conductivity and longevity, housed in a thermoplastic enclosure to resist dust and contamination.
• Compact Design: Dimensions of 5.02 inches in height, 3.5 inches in width, and 4.39 inches in depth allow for efficient use of space in control panels.
• Easy Installation: Equipped with box lug terminals and dual quick-connect options, simplifying the wiring process.

Applications

Engineered for today’s most demanding commercial refrigeration and HVAC applications, the Siemens 42GE35AF106 is ideal for use in:

• Refrigeration systems
• Air conditioning units
• Electric heating systems
• General-purpose motor control

Its enclosed body design ensures quieter operation and a longer life expectancy, making it a reliable choice for various industrial applications.

Specifications

• Number of Poles: 3
• Full Load Amps (Inductive): 90A
• Full Load Amps (Resistive): 120A
• Coil Voltage: 120V AC at 50/60 Hz
• Horsepower Ratings:
  • 15 HP at 240V AC (Single Phase)
  • 30 HP at 240V AC (Three Phase)
  • 50 HP at 480V AC (Three Phase)
  • 50 HP at 600V AC (Three Phase)
• Dimensions: 5.02″ H x 3.5″ W x 4.39″ D
• Enclosure Type: Open
• Contact Material: Silver Cadmium Oxide
• Housing Material: Thermoplastic
• Terminal Type: Box Lug/Dual Quick Connect

For detailed technical information and installation guidelines, please refer to the manufacturer’s documentation.
